Name: WNK ATEX Explosion Proof Submersible Level Sensor for Underground Water Tank
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK8010-TT
Availability: InStock

집 > 상품 > 수위 측정계 >

WNK ATEX Explosion Proof Submersible Level Sensor for Underground Water Tank

ATEX explosion proof water level sensor

submersible water tank level transmitter

underground water level sensor with warranty

원래 장소:

안후이, 중국

브랜드 이름:

WNK

모델 번호:

WNK8010-TT

저희와 연락

인용 을 요청 하십시오

제품 세부 정보

보증:

1년

맞춤형 지원:

OEM, ODM

압력 범위::

0...2~200미터

산출:

4-20mA, 0-5V, 1-5V, 0.5-4.5V, 0-10V

정확성:

0.2%FS, 0.5%FS,

전원공급장치:

12~36VDC

보호 등급:

IP68

애플리케이션:

빗물, 식수, 폐수, 하수, 해수

하우징 재질:

304SS, 316L

작동 온도::

-40~85℃

유형:

계량기

OEM 서비스:

OEM, ODM, 맞춤형 가능

포트:

상하이/닝보

강조하다:

ATEX explosion proof water level sensor

submersible water tank level transmitter

underground water level sensor with warranty

지불 및 배송 조건

최소 주문 수량

1개

포장 세부 사항

각 세트는 하나의 개별 상자에 들어 있으며 거품으로 보호됩니다. 그런 다음 마스터 카톤에

배달 시간

5-8 근무일

지불 조건

T/T, 서부 동맹, MoneyGram, 페이팔

공급 능력

월 레벨 압력 센서당 2000개/개

WNK 4~20mA 0-10V RS485 강과 호수의 스테인리스 스틸 물 탱크 레벨 센서

가장 좋은 가격 을 구하라

비디오

WNK 산업용 등급 4-20mA SS304/SS316L 액체 탱크 레벨 센서 0.5% 정밀도

가장 좋은 가격 을 구하라

비디오

방폭형 수중 수위 센서 4-20mA/0-10V/0-3.3V RS485 출력

가장 좋은 가격 을 구하라

비디오

IP68 방수 0~200m 4~20ma 잠수 액정 레벨 센서

가장 좋은 가격 을 구하라

저희와 연락

지금 연락하세요

제품 설명

Underground Water Tank Level Sensor

Hefei Wnk Smart Technology Co., Ltd. is a professional high-tech enterprise specializing in the R&D, production, sales, and service of various advanced and reliable sensors and transmitters. We are committed to providing users with sensor, transmitter, and product technology solutions tailored to different application needs in different fields. Since its establishment in 2004, WNK has provided reliable products and comprehensive services to customers from over 160 countries worldwide. The goal of WNK is to enable more customers to obtain better products and services at lower prices.

WNK8010 is a high cost effective submersible level sensor suitable for liquid level or pressure and depth measurement. Made of ss304 or ss 316 housing, it can be applied to measurement in most industrial liquids and oils. Each submersible pressure transducer features a removable nose cone at the sensor which protects the diaphragm from damage. It has high stability up to 0.25%FS/Year with high protection of IP68.

Applications

• Water tank level measurement and control.
• Fuel tank level measurement and monitor (diesel, gasoline, kerosene and so on).
• Liquid level measuring in tank, rivers, lake, sea, well, tube, underground water and so on.
• Special occasion such as high temperature liquid (up to 100 degree C), strongly corrosion liquid level measurement (request by customized.)
Features
• Adopting diffusion silicon oil-filled sensor
• Max measure range up to 200 meters or more
• High Stability, provide 0.1, 0.2, 0.5 accuracy for option
• Factory direct price
